Redmyle HRFW 200KVA Stage V Generator

200kVA Stage V Generator

PART.NO. GEN200SV

KEY BENEFITS

200kVA Stage V Diesel Generator
Fuel Consumption at 70% PRP: 29 L/H
Dimensions: (L)4000 x (W)1190 x (H)2100 (mm)
Weight: 3045 (kg)
580ltr Metal Bunded Fuel Tank
Socket Pack: 3 x 32A 230 2P+E, 2 x 32A 3P+N+E, 1 x 63A 3P+N+E

About this Product

The HRFW-200 is our largest Stage V Diesel Generator, producing a total power output of 200kVA, fitted with 3 x 32A 230 2P+E, 2 x 32A 3P+N+E, 1 x 63A 3P+N+E sockets and a 580ltr internal bunded fuel tank for short term power generation (recommended to be used with additional bunded fuel tank for continuous use). This generator is perfectly suited as a temporary power source for larger projects on construction sites, temporary work spaces, industrial areas and events venues with access to outside space.



Available to Hire across mainland UK with easy delivery from our 3 UK locations; Surrey, Rochdale and Glasgow. Redmyle also offers convenient fuel management packages, delivering regular diesel refilling services tailored to the needs of your business.



Why Choose a Stage V Diesel Generators



Our Stage V Diesel Generators have been specifically designed to be compliant with EU Regulation 2016/1628/CE aimed at limiting the amount of emissions produced by internal combustion engines, installed in non-road mobile machinery (NRMM), used within large populated cities such as London, Birmingham and Manchester. Using a sophisticated built in exhaust treatment system, these generators clean the fumes expelled by the engine before they are released into the atmosphere. This process provides a reduction of up to 90% of environmentally hazardous gases and particles compared to previous technology.

Power Output 200kVA
Fuel Consumption at 100% PRP 41 L/H
Fuel Consumption at 70% PRP 29 L/H
Noise Level at 7m 66 dB(A)
Generator Dimensions L x W x H (mm) 4000 x 1190 x 2100
Weight with liquids in radiator and sump (kg) 3045
Internal Metal Bunded Fuel Tank 580ltr
Engine Iveco - Stage V Diesel Engine
Filter Racor filter with alarm
Alternator Stamford Alternator - UCI274H
Breaker Schneider Motorised Type 'D' Breaker 4P 400AMP Breaker
Fuel Valve 3/8" - 3 way valve kit and fast connection fittings for fuel decanting
Socket Pack 3 x 32A 230 2P+E, 2 x 32A 3P+N+E, 1 x 63A 3P+N+E
Dual Frequency 50/60Hz
RCBO 2 x 32A 3P+N+T and 3 x 32A 2P+T
Control Panel DSE890 (MKII) Gateway & Antenna with GSM and GPS
